3.6/6 kV XLPE Insulated, Flat Wire One Core Cables With Copper Conductor

Applications:In dry and damp rooms, locations and store rooms where subject to fire and explosions hazards, but not for underground laying. For permanent installation clear from in and under plaster.
Technical Data
Permissible operating temp. : 70 °C
• Maximum short circuit temp. : 160 °C
• Test voltage (AC): 2kV
• Installation temp. min: -5 °C

Normal Kesit  Tip Kablo  Dış Çapı  Akım Taşıma Kapasitesi  İletken  DC Direnci  (20°C)  Net Ağırlık  Sevk Uzunluğu
mm2    mm  Havada  Toprakta  Ohm/Km  KG/KM  Mt
2X1  6242Y  0.9  19 11 18,1 53 100
2X1,5  6242Y  0.9  25 16 12,1 70 100
2X2,5  6242Y  1 34 21 7,41 105 100
2X1+1  6242Y  0.9  19 11 18,1 76 100
2X1,5+1  6242Y  0.9  25 16 12,1 100 100
2X2,5+1,5  6242Y  1 34 21 7,41 150 100
3X1  6242Y  0.9  19 11 18,1 68 100
3X1,5  6242Y  0.9  25 16 12,1 85 100
3X2,5  6242Y  1 34 21 7,41 120 100
3X1+1  6242Y  0.9  19 11 18,1 91 100
3X1,5+1  6242Y  0.9  25 16 12,1 115 100
3X2,5+1,5  6242Y  1 34 21 7,41 170 100
